24V DC Permanent Magnet Motor White Linear Actuator Medical Bed
Motor
Features:
24V DC permanent magnet motor Push force up to 6000 N, pull force
up to 4000 N Color: grey or black Standard protection level: IP54
Stainless steel tube with inner tube Average noise level below 45dB
(Ambient noise is less than 40dB). Built-in electronic limit switch
High strength front and rear clamps Certificate: CE, UL60601-1,
IEC60601-1
Technical Parameters:
Max. load push(N) | 6000 | 4000 | 2000 | 1000 |
Max. load pull(N) | 4000 | 4000 | 2000 | 1000 |
Static Load push*(N) | 6000 | 4000 | 2000 | 1000 |
Static Load pull*(N) | 4000 | 4000 | 2000 | 1000 |
Input(VDC) | 24 |
Speed at Full Load(mm/s) | 3 | 4 | 8 | 12 |
Stroke Length(mm) | 100~400 (option>400 ) |
Mounting position | H type,V type |
Colour | Black or Grey |
Limit Switch | Built-in |
Overload Protection | Yes |
Duty cycle | 10%, max 2min. continuous use |
IP Grade | IP54 |
Operating Temperature | Reed switch option |
Only push option |
Safety nut option |
Standard | CE / UL |
