Electric Bed Linear Actuator Control Box Multiple Application Scenarios

Ask Lasest Price
Brand Name :	KENYUE
Model Number :	KY-B35T2
Certification :	CE ISO
Price :	15USD/PCS
Payment Terms :	T/T, L/C
Supply Ability :	1000pcs/month
Delivery Time :	10-15DAYS

Add to Cart

Product Details
Company Profile

Electric Bed Linear Actuator Control Box Multiple Application Scenarios

Actuator Controller control box is suitable for electric bed multiple application scenarios

Linear actuator controller

Description

Features:

1. Power supply: input (universal): 100-240VAC, 50/60 Hz;
2. The output power is 72W in the rated state, and the output power is 200W in the working mode.
3. Power cable: fixed cable (3m, gray and white)
4. Power indicator: Yes
5. Output voltage: 30~36VDC
6. Maximum output current of switching power supply: 10A, minimum voltage 20V
7. Standby power: maximum 1W without battery
8. Hand controller interface: crystal curved plug
9. Control concept: H bridge, with a service life of more than 20,000 cycles (applicable to signal switches)
10. Push rod interface: 4 channels (6P connector)
11. Putter compatibility: small signal putter
12. Operation: Synchronous drive
13. Security system: switching power supply thermal protection, hot plug protection
14. The highest degree of protection: IPX6
15. Color: off-white
16. Installation: Compatible with push rods equipped with special mounting brackets; bed frame (via screws, sliding brackets)
17. Line card: all ports have
18. Duty cycle: 2/18 @ 25°C; continuous use on/off (power 200W at 25°C for 120 seconds)
19. Weight: 696g
20. Endpoint protection feedback: signal switch

specifications


Number of actuators	1-4
Frequency of use:	10%, up to 2 minutes of continuous work
color	white
Protection level	IPX6
Maximum output voltage (VDC):	36
Input voltage (VAC):	100~240

Electric Bed Linear Actuator Control Box Multiple Application Scenarios
