Medical grade adjustable oxygen generator 5L oxygen concentrators
equipment
oxygen concentrator
specification
1,Power supply: AC220V, 60Hz; Current: 3.5A; Power: 390VA
2,Sound level: ≤ 50dB (A)
3,Maximum recommended flow:5L/min4,Flow Range at Outlet Pressure of
zero: 0.5～
5L/min Flow Range at Outlet Pressure of 7 kPa:
0.5～5L/min
Change in maximum recommended flow when back pressure of 7 kPa is
applied:
＜ 0.5 L/min
5,Oxygen Concentration: When 0.5~5L/min ,93%±3% (after turning on
30 minutes)
6,Output Pressure: 38kPa±5kPa ;
7,Release Pressure by machine operation: 250kPa±50kPa;
8,Weight: 15kg；
9,Dimension: 330×260×540(mm)；
10,Height above sea level: The oxygen concentration will not
decrease on 1828 meter height
above sea level, from 1828 meter to 4000 meter; the efficiency will
decrease to less
than 90%.
11,Safety System:
① Current overload or line surge shutdown.
② High temperature compressor shutdown.
③ High pressure alarm shutdown.
④ Low pressure alarm shutdown.
⑤ Low Oxygen Concentration alarm.
12Minimum Operating Time: 30 minutes
13:Electric Classification: Class Ⅱ equipment , Type BF applied
part(Nasal
oxygen cannul
14 , Mode of operation: Continuous duty15, Normal Operating
Ambient: over voltage category: II
pollution degree: 2 altitude:≤2000
Rated voltage | AC220±22V50±1Hz/AC110±10V 60Hz |
Oxygen flflow rate | 0.5~5L/min |
Oxygen concentration | 95.5%-87% |
Oxygen pressure | 40kPa-70kPa |
Operating noise | 52dB(A) |
Input Power | 400VA |
Size | 50*39*25cm |
Net weight | 15.5kgs |
Jiaxing Greatmicro Medical Equipment Co., Ltd. is located in Jiaxing City, the Yangtze River Delta Economic
Circle, with a developed economy and convenient transportation. Our
factory combines the manufacturing, sales, service and support of
the most innovative hospital furniture solutions, managed by a
professional team with extensive management experience and business
acumen in various
fields, and is a leading provider of highly specialized medical
equipment and equipment Products, such as electric and manual
hospital beds, orthopedic traction beds, examination beds, infusion
chairs, accompany chairs, hospital trolleys, stretchers and
stretcher trolleys, have passed ISO9001: CE certification. In
addition to all these certificates, we are also committed to
providing customers with a one-stop sales model, and we pay more
attention to customer satisfaction, which is the basis for making
our products popular on a global scale. So far, more than 60
countries and regions have enjoyed our products and services. Our
success is mainly achieved by following the firm commitment to the
corporate philosophy of "integrity-based, customer first". Our
vision is to provide world-class products and services to improve
the global medical system to the highest level.
We have a professional team:
1. A professional team of engineers to ensure high quality products
and provide professional product customization services.
2. The professional material procurement team reduces the cost of
products and provides our products with competitiveness.
3. Professional business team to ensure smooth communication to
bring you a good experience.
4. Professional document clerk and merchandiser team to ensure the
smooth delivery of products.
Our products have been exporting to Europe,North America,South
America,Middle East of Asia, India, indonesia, Egypt, Algeria,
Sudan, Africa,Saudi Araba, etc. Also we could offer OEM/ODM
manufacturing as customers prefer.
Q: Where is your factory?
A: Jiaxing City, Zhejiang
province, China. 2hours from Shanghai.
Q: What are the main products?
A: main products are nursing beds,stretchers,connecting
stretchers, baby cart, trolley,cabinet and other accessory parts.
Q: What’s your advantage?
1.We have a professional managing
team; most of them are working in this field more than 5 years. We
have established a long-term cooperation relationship with some
of our customers recently. 2. ISO9001, Quality Management System;
3.Strict Material Inspection&Quality Controlling; 4. CE,ISO
Certificate; 5. We started from 2011, more than 10 years producing
and engineering experience; 6.Exported to more than
30countries
